The main performance specification table
1. Model CA-3000 worm sliding door (single/double)
2. Type one-way horizontal open and two-way open
3. Door leaf weight 200 kg X 1 , 150 kg X 2 fan
4. DW door leaf width = 500 mm to 2500 mm per fan DW = 500 mm to
2500 mm per fan
5. According to the loading way according to the loading surface
under the surface
6. Brushless DC motor DC 24 v, 75 w Worm motor
7. The controller of intelligent microcomputer processing
controller
8. Power consumption 75 W
9. AC power supply voltage 80 v to 250 v
10. Ambient temperature - 20 ℃ ~ + 50 ℃
11. Most noise 60 decibels
12. Open speed 600 mm/SEC 550 mm/SEC
13. Open the stop time can be adjusted to 20 seconds with 0.5
seconds left
14. The transmission elements 150 S8M toothed belt
15. Open the door by full/half open Can adjust the distance
16. External numerical control mode L - 138 special regulator
17. Push open power 3 kg
Features:
1. Can be directly connected infrared, construction is convenient,
such as electric lock, UPS.
2. The large range of voltage stabilizing system, affordable AC80V
~ AC250V plus or minus 10% of the power input.
3. When they run into any obstacles or the human body, can
immediately reverse, a substantial increase in users in and out of
safety.
4. Add signal amplification device, make the door machine and
matching, access control, attendance, and fire systems are more
stable and safe.
5. The AD hoc fully open, half open (adjustable) function can adapt
to different regions and different places of different switch range
of traffic
Requirements, provide human nature to change more.
6. A power factor correction function, reduce unnecessary energy
waste, to alert the user choose automatic door is installed
When set, generally do not consider the negligence of electricity
consumption.
1. The large range of voltage stabilizing system (input voltage 80
v to 250 v gm)
2. Save electricity function (PFC) 95%
3. The silent multi-functional high resistance to low temperature
4. All series using toothed belt drive good, high stability
5. CE certification
Brushless DC motors
Features:
1. Internal control provide acoustic closed design, the motor
running quiet, no noise.
2. Increase the torque improvement, make the motor can carry
heavier, more stable operation.
3. The reducer adopts stainless steel casting, is by no means
industrial plastic or made from cast iron, the host in a long
uninterrupted high-speed operation
State, the more durability.
4. The drag reduction of driving wheel design, make the door leaf
in the case of power failure, only 3 kg force can be manually
opened, the old man and woman
Female, child all can do, greatly enhance the safety of automatic
door.
