Door body |
NO. | Term Name | Content | Quantity | Origin | Note |
01 | Revolving door frame | Aluminum alloy frame structure | 1Set | Shandong | National Standard 6063 T5 |
02 | Revolving door leaf frame | Aluminum alloy profile frame | 1Set | Shangdong | National Standard 6063 T5 |
03 | Revolving door leaf brush | Black wool,tightness door body, anti-wind and sand | 1Set | Menggu | WAFE |
04 | Revolving door ceiling light | Revolving door ceiling light,LED 1W×3 | 6pieces | Guangdong |
|
05 | Drive system | Body rotation operation system,Seiko production | 1Set | Shandong | NE Precision |
06 | Bearing the under the door body | Used for door body bearing | 1Set | Shandong | NE Precision |
07 | Door operation bearing | Door body with rotating bearing | 2Sets | Japan | NSK |
08 | machine parts | Hardware | 1Set | Shandong | NE Precision |
09 | Turnstiles cove plate | White MDF | 1Set | Guangdong |
|
Door body glass |
NO. | Term Name | Content | Quantit | Origin | Note |
01 | Curved door tempered | 8mm Curved tempered glass | 1Set | China |
|
02 | Revolving door glass Curvedoor tempered | 6mm Tempered glass | 1Set | China |
|
Electrical control and radar detect safety device |
NO. | Term Name | Content | Quantity | Origin | Note |
01 | Revolving door centre contro system | 14 spot PLC programmable controller system | 1Set | Japan | Panasonic |
02 | Door body running program | NE Professional development,Mature and stable | 1Set | Qingdao | NE |
03 | Revolving door converter controller | 220V,0.75Kw,Door body operation speed regulation | 1Set | Janpan | Panasonic |
04 | Model select controller | Touch screen control, computer interface , design easy to operate | 1Set | Japan | Panasonic |
05 | Revolving door motor | 220V/50Hz/0.25 KW | 1 Set Set | Germany | Lenze |
06 | Motor reducing gear | Door body speed ratio | 1 Set | Germany | Lenze |
07 | Electromagnetic clutch | Use lock the door , | 1 Set | Germany | Lenze |
08 | Slow rotation function | By 15Hz rotate,when people pass change to normal speed | ---- | ----- | Standard specification |
09 | Normal rotation function | Normal speed rotate when people pass,door body stop at the setting
position when no people pass | ---- | ----- | Standard specification |
10 | Revolving door overhead light control | Touch screen control overhead light,easy operate | ---- | ----- | Standard specification |
11 | Lock door function | Choice the instruct on touch screen,revolving door automatically
lock the door | ---- | ----- | Standard specification |
12 | Failure display function | Display the door body fault on the touch screen,easy to maintenance | ---- | ----- | Standard specification
|
13 | Inboard sensor | Install at the above door inward and outward | 2pieces | Belgium | biye |
14 | Infrared prevent nip sensor | Installed on the revolving door hat head | 2pieces | Belgium | biye |
15 | Anti-collision sensor | Installed on door body’s light side post. | 2Sets | Swiss | BIRCHER |
16 | Tracking sensor | Installed on the bottom of the door leaf | 3Sets | Swiss | BIRCHER |
17 | Signal sliding loops | Feeble electricity signal transmission | 1Piece |
| Quansheng |
18 | Disabled button | Located at inlet and outlet upright | 2Pieces | Japan | Fuji |
19 | Emergency stop button | Located at inlet and outlet upright | 2Pieces | Japan | Fuji |
| | | | | | | | | | | | |
