Autodoor technical parameters:
| Door style | single leaf or double leaf |
| Door width | 650mm~1300mm |
| Door weight.max | 150kgs 150kgsX2 |
| Power supply | 80VAC~250VAC, 50/60Hz |
| Voltage output | 12V DC, 24V DC |
Brushless Motor | 70W,24V DC |
| Opening speed and closing speed | 250~550mm/S |
Creep speed | 20~100mm/S |
| Manual opening Force | <50N |
| Hold-Close Force | 150N<f<250N |
| Hold-open time | 0-15s (adjustable)
|
Description:
1. A digital display and indicator light directly provides
information regarding the status of the doors.
2. Adopting digital communication mode to set parameters, avoiding
using screwdriver to set parameters, so avoiding long-term contact
point oxidated to make parameter changed.
3. The wide voltage range can meet undervoltage and the wide
voltage fluctuation.
4. Complete functions can make users to choose various modes to
open and close doors.
5. Reasonable mechanical structure, and beautiful surface
treatment, making installation and debugging easy
6. There are remote parameter setting interface in the controller,
realizing wireless remote parameter setting.
7. Powerful intelligent self-closing function, at the statue of
locked, computer will output changeable intelligent power to motor
through monitoring doors, it is energy-efficient and can realize
safe closing.
8. Main function interfaces include: permanent open, partial open,
inside lock, outside lock, full lock, fire alarm, interlock, card
reader, safety beam sensor.
9. Humanization design, making door installation and wiring easy.
10. Manual mode and remote control mode to realize quick and easy
mode change.
11. Using digital microprocessor, and adopting contactless control
for inside signal loop, open and close accurately.
12. Adopting DC brushless motor, and worm gear, worm rotation,
starting torque is big, quiet running, long life, especially for
quiet environments, such as office building, bank, apartment
building.
Machine PIcture :
