    Super Slim Residential Automatic Sliding Doors Width 600mm To 900mm

    Ask Lasest Price
    Brand Name : Caterly
    Model Number : D-H
    Certification : CE,ISO9001:2008
    Price : USD200.00/set to USD 450 .00/set
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 3,000 Sets per Month
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    Super Slim Residential Automatic Sliding Doors Width 600mm To 900mm

    Super slim Residential Automatic Sensor Glass Sliding Door , Residential Automatic Sliding Doors

    Feature



    1. Brush Motor 25W ,powerful enough to bear 2X30KG gates.

    2. Easy install since the Drive system has been installed before leavine the factory

    3. CE approved

    4. Motor lock


    Emergency Functions

    Emergency opening in case of power failure / Fail-safe
    Obstacle detection with automatic return mechanism
    Self monitoring light barriers

    Specifications

    1) 24 months warranty
    2) loading capacity:30kg*2
    3) anti-pinch function
    4) manual open-automatically open function



    Automation


    Control unit8 bit-slice microcomputer system
    TransmissionToothed belt and motor drive
    Use frequencyContinuous
    Opening speed15-50cm/s (adjustable)
    Closing speed10-45cm/s (adjustable)
    Braking speed3-10cm/s(adjustable)
    Open time0-8 s
    Braking distanceadjustable
    Manual forceless then 42N
    Door weight1 x 60kg, 2 x 30kg
    MotorBruthless, China-made
    Programremote control,digital display

    Components


    Retro-fit kit of automatic sliding door

    1

    Motor & Gearbox

    1pcs

    China-made 24V,25W ,DC bruthless motor

    2

    Microcontroller

    1pc

    8 bit Microchip chip

    3

    Radar

    2pcs

    Bea radar

    4

    Learning code remote controller

    1set

    Hold-open,lock,exit only, half-open

    5

    Carriage

    4pcs

    2 running wheel

    6

    Tooth belt

    1pc

    8m, fiberglass tensile elements, nylon surface

    7

    Belt clamp

    2pcs


    8

    Idle pulley

    1pc

    Aluminum alloy

    9

    Stopper

    2pcs

    Aluminum alloy

    10

    Connection termial

    1pc

    For 110V to 220V power ,and outside sensor connection

    Profile

    1

    Track

    1pc

    3mm thickenss, Anodize, height 125mm, depth 100mm,length 4200mm

    2

    Cover

    1pc

    170mm height,anodized

    Options

    1

    Safety beam sensor

    1set

    China-,made

    2

    Electro-mechanical lock

    1set

    12V,time delay

    3

    Emergency battery

    1set

    12V,7Ah,contiunously working half an hours

    4

    Control panels

    1set

    LCD display, key swtich,5 program adjust

    5

    Floor guide

    2pcs

    For frame and frameless door

    6

    Glass clamp

    2pcs

    1m length, fit to 10mm,12mm glass


    Automatic sliding galss door for restensial
