    Fashionable Slender Portal Powered Sliding Doors For Office Building With Radar Sensor

    Ask Lasest Price
    Brand Name : CATERLY
    Model Number : F-120W
    Certification : CE,SGS,ISO9001:2008 ,CQC
    Price : 250 usd to 350 usd
    Payment Terms : T/T, Western Union, L/C,paypal, MoneyGram
    Supply Ability : 1500 sets per month
    Delivery Time : 3 to 5 days after get payment
    • Product Details
    • Company Profile

    Fashionable Slender Portal Powered Sliding Doors For Office Building With Radar Sensor

    Fashionable Slender Portal Powered Sliding Doors For Office Building With Radar Sensor


    Intelligence The sliding operator is controlled by micro computer chips. It is easy to install and use. The operator can automatically adapt itself to different door weight.

    Safety The sliding operator have the alarm system which can prevent people from nipping, so it is safe for users. With motor self lock function, the operator can lock the door without mechanical locks. The door leaf will automatically turn back if it touches any obstacles.

    Reliability Thanks to professional mechanic design and high-efficiency DC brushless motor, the sliding operator can work very well with low noise for a long time. With the help of advanced synchronous belt and perfect design of power supply circuit , the door moves very stably.

    Energy Saving With the help of semi-open function, so this can help to keep the temperature and humidity inside the room and to minimize the costs of the air conditioner as well.

    Convenience All the adjustments can be implemented with adjust controller. It is facilitate to operate the operator. Open and close smoothly with high efficiency. Fast installation and easy replacement for assembly parts.


    Specification


    Single Drive System/MotorDouble Drive System/Motor
    Weight of gate Single/Bi-part1X120KG2X120KG
    Width of gate Single/Bi-part700-1500MM650-1350MM
    Master Controller32 digital microprocessor32 digital microprocessor
    Brush motor70W70W
    Opening speed450-750mm/s450-750mm/s
    Closeing speed450-750mm/s450-750mm/s
    Max open strength150N285N
    Hold Open Time/Lock0-10S/30s0-10S/30s
    Height of the rail18CM18CM
    Deepth of the rail16CM16CM
    Power SupplyAC80V-250V 50/60HZAC80V-250V 50/60HZ
    Temp-20ºC to +50ºC-20ºC to +50ºC
    Power Consumptionaround 70Waround 70W

    Emergency Functions

    Emergency opening in case of power failure / Fail-safe
    Obstacle detection with automatic return mechanism
    Self monitoring light barriers
    Slow speed search for obstruction


    Additional

    Low noise desigh (<40db)

    One million times of tests passed

    Warranty: 18months

    Packaging & Delivery


    Packaging Detail:Carton&Bubble Bag
    Delivery Detail:Less than 7 days IF Quantity less 50sets

    Optional Parts

    Motion Sensor

    Lock latch

    Battery

    Beam safety photocell
